Installing Server 3-9
A rack-mount model is shown here. As for a tower model, locations of the connectors are same
though the orientation of the equipment is different.
IMPORTANT: Space of 1U above the main unit is needed to place the USB floppy disk
drive on the main unit for a rack-mount model. For a tower model, place it on the main
unit.
IMPORTANT: Connection of optional devices
In the case of standard configuration, you need to complete setup of the operating
system before mounting optional PCI cards or hard disks that you purchased
separately.
If N8803-031F is mounted, be sure to connect cables to the FC array unit before going
on to the next step.
Display
To a 1000Mbps
network To a 100Mbps
network To a SCSI
backup device
Keyboard (via keyboard hub to mouse)
Reserved for
maintenance Reserved for
maintenance
USB floppy
disk drive
