Troubleshooting 6-9
Updating the System
IMPORTANT: NEC Express5800/ft series is a precision instrument. You should ask
maintenance personnel to update the system.
You will need to update the system after you repair the system using Recovery Console.
IMPORTANT:
Make sure to follow the steps below when you have restored the system by using Recovery
Console.
Check the configuration for boot monitoring function.
If [Boot Monitoring] selected in [Monitoring Configuration] of [Advanced] is not set to
“Disabled”, disable it. See “Disable Boot Monitoring Function” (4-11) for details.
1. Log on to the system with OS installed as user with Administrative account.
IMPORTANT: Check that the dual system is configured properly. (Check that STATUS
LED 2 of each PCI module stays green.)
2. Remove duplication of LAN for both onboard and option boards.
IMPORTANT: When dual LAN is disabled, a setup of LAN will be deleted. Note down
the setup information.
1) Display the [Intel(R)PROSet II] dialog box.
2) Start up one of the following start menu modes by according to its procedures.
Standard startup menu mode:
Click [Start] and select [Control Panel], and then [Intel(R)PROSet II].
Classic start menu mode:
(1) Click [Start] and select [Settings], and then [Control Panel].
(2) Double click the [Intel(R)PROSet II] icon.
3) Remove all adapters from Duplication.
Right-click the following adapters on the control tree which is located on the left side of
the [Intel(R)PROSet II] dialog box and select [Remove from Team].
