4-12 Windows Setup
3. Confirm that the BMC Status LED ( ) on both PCI modules are off and press the
illuminated POWER switch which is located on the front panel.
* Only the lit POWER switch can be used.
IMPORTANT:
Do not turn off the power before the "NEC" logo appears.
When powering on, make sure that the BMC Status LED ( ) on the both
PCI modules are off and then press the power switch.
After a while, the "NEC" logo will appear on the screen.
While the "NEC" logo is displayed on the screen, NEC Express5800/ft series is performing
a power-on self test (POST) to check itself. For details, see the separate volume of User’s
Guide. Upon the completion of POST, Windows will start.
CHECK: If the server finds errors during POST, it will interrupt POST and
display the error message. See the separate volume of User’s Guide.
BMC Status LED
PCI modules CPU modules POWER switches*
