138
Appendix B
Specifications
B.1 Network Card
The following table provide general specifications for the Network Card.
B.2 Network Cable
Use the following universal Ethernet standard when configuring your RJ-45 connector
of network cable to connect to the 100BaseTX/10BaseT connector of the Network
Card.
Important: For 10BaseT use Category 3, 4 or 5 shielded cable.
For 100BaseTX use Category 5 shielded cable.
Network Card General Specifications (Small Board)
Size: 123.7 mm length x 95 mm height
Weight: 8 ounces
Environment: 0 to 50 degrees Centigrade, 5% to 80% humidity
Controls and Indicators: One green LED and one amber LED
Configuration: Stored in non-volatile memory
Connectors: Ethernet: 8-wire RJ-45 100BaseTX/10BaseT
Pin Number Color Ethernet
8 blue/white
7 blue
6 orange/white Receive -
5 green/white
4 green
3 orange Receive +
2 brown/white Transmit -
1 brown Transmit +
