User Cleaning Schedule
93
LED air filter 703543-001 2,400,000 Replace H
Tractor belt, 3M264 793531-031 2,400,000 Replace H
Drum belt, 3M264 703531-031 2,400,000 Replace H
Capacitor (see WARNING
on next page)
703542-001 2,400,000 Replace H
LED for discharge lamp 703531-118 2,400,000 Replace H
Feed Roller 703531-563 2,400,000
See Note 2 Clean and
inspect:
replace if
worn, H
Resist Roller 703531-565 2,400,000
See Note 2 Clean and
inspect;
replace if
worn. H
Roller; Pre Drum 703531-590 2,400,000 Clean and
inspect;
replace if
worn, H
Lever, Empty 202840-001 2,400,000
See Note 2 Clean and
inspect;
replace if
worn H
EPS1 Sensor Lever 703531-585 2,400,000 Replace H
EPS2 Sensor Lever 703531-588 2,400,000 Replace H
EPS3 Sensor Level 703531-067 2,400,000 Replace H
Note 1: When the cleaning unit has been vacuumed every 150,000 pages and has been used
under nominal operating conditions, it must be replaced at 600,000 pages. However, it may
need to be replaced more frequently if used for high-density printing or printing on uneven
media, or if used under severe operating conditions.
Note 2: Only applies to printers with the cut sheet option installed.
