Chapter 3 Consumables Replacement
68
23. Install the lower inner cover and secure with the two screws
removed earlier.
24. Install the drum plate and tighten the thumbscrews. While
installing the drum plate, place your thumb over the copper
grounding clip and hold it in place. Otherwise the grounding clip
can be bent, making no contact with the drum shaft.
25. After installing the drum plate, visually verify good electrical
contact between the copper grounding clip and the end of the
drum shaft.
Alternatively, measure the resistance. Connect one lead of an
ohmmeter to the bracket on the drum plate, and touch the other
lead to the edge of the drum. Normal resistance should be 0
Ω
.
26. Install the developing unit.
27. Raise the transport unit. (Refer to Step 10.)
28. Install the upper inner cover and tighten the thumbscrews.
29. Close the waste toner recovery unit and ensure that it latches.
30. Close the printer front cover.
Proper Disposal Of A Drum Unit
Due to the nature of the material used in drum manufacturing,
federal regulations prohibit inappropriate disposal of laser print
drums. Dispose of used drums by shipping them to one of the
following:
Within U.S.A.
U.S. Fuji Electric Inc.
240 Circle Drive N.
Piscataway, NJ 08854
Attn: Rod Storm
Phone: (732) 560-9410 Outside U.S.A.
Fuji Distribution Europe B.V.
Attn: Mr. Asada
Leisteen 7,2132 ME
Hoofddorp,
The Netherlands.
TEL: 20-6534790
