Chapter 2 Loading Paper
32
2. Load the new paper uniformly in the cassette, making sure the
leading edge of the paper is at the front of the cassette. Do not
load more paper than specified below, otherwise a paper jam
may occur.
Legend:
1) Cassette Cover
2) Cassette
3. Cover the cassette and insert it fully into the printer, making
sure it is completely seated. If the cassette is not fully seated, a
paper jam may result.
17-20 lb.
bond Upper
cassette
Lower
cassette 250 sheets or less
500 sheets or less
21-44 lb.
bond Upper
cassette
Lower
cassette 1 inch or less in
thickness
2 inches or less in
thickness
1
2
