Install the upper and lower reverse roller units, B. tighten the green thumbscrew, 1) coupling – Printronix L5535 User Manual
Page 120: 2) hole in the frame, 3) shaft pin, 4) alignment pin, Chapter 4
Chapter 4
General Cleaning
120
10. Install the upper and lower reverse roller units:
a.
Align the shaft pin with the slot in the coupling, and align
the alignment pin on the unit with the hole in the frame.
b.
Tighten the green thumbscrew.
Legend:
1)
Coupling
2)
Hole In The Frame
3)
Shaft Pin
4)
Alignment Pin
11. Install the upper and lower paper cassettes into the printer.
2
4
1
3
