Chapter 2

Physical Description

40

Physical Description

The front (output side) of the power stacker is shown in the
following illustration.

Legend:

1)

AUTO Key

2)

STOP Key

3)

DOWN Key

4)

HEAVY Key

5)

Hook

6)

Head/Tail Length Measuring Gauge (in inches)

7)

Safety Stop Bar (not visible in figure)

8)

Elevator Table

9)

Top/Bottom Adjustment Knob

9

8

7

6

5

4

3

1

2
