User Cleaning Schedule
83
Level B Maintenance - 150,000 Pages(User)
Action Item Part # Performed By Date
Clean General cleaning n/a
Clean Main charger 705741-001
Clean Precharger 705742-001
Clean Transfer charger 705743-001
Clean
See Note1 Cover glass n/a
Clean SELFOC lens n/a
Vacuum Lamp housing filter 202838-001
Vacuum Cleaning unit 705740-001
See Note 2 Photoreceptor drum 703535-001
Replace
See Note 3 Toner cartridge 703532-001
Replace Developer 703548-001
Replace Waste toner bottle 703539-001
Replace
See Note 4 Cut sheet cassette
pickup rollers 703531-050
Replace
See Note 4 Cut sheet cassette
reverse rollers 703531-051
Note 1: Every 15,000 pages or every 6 paper jams, whichever occurs first.
Note 2: Inspect every 150,000 pages; clean if needed. Replace at 300,000 pages or sooner if
print quality is no longer acceptable. Drum life is dependent upon media being used and proper
maintenance and operation of the printer. Print media other than bond paper (e.g. labels, card
stock, plastic, or vinyl) may reduce drum life as much as 50%.
Note 3: Replace the Toner cartridge approximately every 21,000 pages or as needed (for page
coverage of 4%).
Note 4: Only applies to printers with the cut sheet option installed.
