Chapter 4 Maintenance Tools
78
If the print quality is still poor after cleaning the printer, the chargers
may need to be replaced. Contact your authorized service
representative for further assistance.
NOTE: For replacement intervals, see the maintenance schedules
that begin on page 81. For replacement procedures, see
Chapter 3, “Consumables Replacement."
Maintenance Tools
In order to perform maintenance on the printer, the following tools
are required:
Recommended toner vacuum cleaner models are:
• 3M
®
model 497-AJM standard VAC with Type 1 filter
• 3M model 497-AB 220V with Type 1 filter
• Hitachi
®
CV-TN10 with TN-15 filter
Item Part Number
Brush cleaner 703531-169
Drum auxiliary rod 703531-170
Drum freshener pad 703531-171
Fuser cover glass scraper 703531-187
Special dry tissue paper 703531-188
Standard toner vacuum cleaner See recommended
models below.
Toraysee cloth 703531-183
Wire cleaner 703531-168
9 inch Phillips #1 screwdriver N/A
