1) fuser unit, 2) cleaning unit, 3) discharge led (not visible) – Printronix L5535 User Manual

Page 23: 4) main charger, 5) toner cartridge, 6) optional cut sheet paper input cassette, 7) control panel, 8) developing unit, 9) waste toner recovery unit, 10) transport unit

background image

23

Legend:

1)

Fuser Unit

2)

Cleaning Unit

3)

Discharge LED (not visible)

4)

Main Charger

5)

Toner Cartridge

6)

Optional Cut Sheet Paper Input Cassette

7)

Control Panel

8)

Developing Unit

9)

Waste Toner Recovery Unit

10) Transport Unit
11) Smoke Filter Box
12) Power Supply for Flash Lamp

Figure 3. Front View with Front Upper Cover Removed

1

2

12

11

10

9

8

7

6

3

4

5
