8-6 8-6 8-6 8-6
8-6 | Specifications
Parallel Interface
Forward Channel
Reverse Channel
ECP Mode
Data format 8-bit parallel, IEEE-1284 compatibility mode
Synchronization STROBE pulse
Handshake timing BUSY and ACKNLG signals
Signal level TTL compatible
Connector 57-30360 Amphenol connector or equivalent
Transmission mode IEEE-1284 Nibble mode
Adaptable connector 57-30360 Amphenol connector or equivalent
Synchronization Refer to the IEEE-1284 specification
Handshaking Refer to the IEEE-1284 specification
Signal level IEEE-1284 Level 1 device
Data transmission timing Refer to the IEEE-1284 specification
Transmission mode IEEE-1284 ECP mode
Adaptable connector 57-30360 Amphenol connector or equivalent
Synchronization Refer to the IEEE-1284 specification
Handshaking Refer to the IEEE-1284 specification
Signal level IEEE-1284 Level 1 device
Data transmission timing Refer to the IEEE-1284 specification
