Saving and Recalling Configurations
82
m40L/m46L Installation & Configuration Guide
Switching Modes
Suppose you set up the Black and White Levels for a 1024 x 768 @ 65Hz from a
computer connected to analog. Then later, using the same input connector but a
different computer, you set up the display for a 1600 x 1200 @ 60Hz. You re-adjust
the Black and White Levels, because they are different.
Still later, you plug in the first computer with its 1024 x 768 @ 65Hz picture.
Immediately, the display recognizes that it has seen this signal type before, and it
recalls the Black and White Levels from its internal memory.
It does not do Frequency or Phase or anything else, because it recognizes that this
input was used before, and the previous settings are probably correct.
However, suppose that after setting up the 1024 x 768 and 1600 x 1200 pictures, you
connect a third computer that is 1024 x 768, but it has different requirements for
Black and White Levels. In this case, the display would use the values for the levels
you set up for the first computer. To prevent this from happening, use the memory
slots to save this specific configuration.
Saving Configurations
1
Set up the display the way you want it.
2
Press the
SAVE
button twice.
The
SAVE
grid menu displays. This menu contains 40 numbered memory slots.
3
Using the arrow keys on the remote, navigate to a slot:
• An unchecked slot number allows you to save new settings.
• A checked slot has settings already saved to it. If you want, you can overwrite
what’s already saved.
S a v e
1
9
1 7
2 5
3 3
2
1 0
1 8
2 6
3 4
3
11
1 9
2 7
3 5
4
1 2
2 0
2 8
3 6
5
1 3
2 1
2 9
3 7
6
1 4
2 2
3 0
3 8
7
1 5
2 3
3 1
3 9
8
1 6
2 4
3 2
4 0
