Automatically Selecting the Source
26 m40L/m46L Installation & Configuration Guide
• Composite
• Component (YPbPr)
• SDI
Note: For additional information about source selection, see "Preferred Source Detection" on
page 60.
P i c t u r e
S o u r c e C o m p Vi d e o
Vi d e o Sta n d a r d N T S C 6 0 H z / 3 . 5 8 M H z
Ve r t i c a l F r e q u e n c y ( f r a m e l o c k e d ) 6 0 H z
S h a r p n e s s
I n p u t L e v e l s
P i c t u r e
S o u r c e C o m p o n e n t ( Y P b P r )
Vi d e o Sta n d a r d N T S C 6 0 H z / 3 . 5 8 M H z
Ve r t i c a l F r e q u e n c y ( f r a m e l o c k e d ) 6 0 H z
H o r i z o n ta l F r e q u e n c y 5 0 . 0 0 k H z
H o r i z o n ta l R e s o l u t i o n 1 3 6 6
Ve r t i c a l R e s o l u t i o n 7 6 8
F r e q u e n c y 1 6 0 2
P h a s e 2 2 . 5 °
S h a r p n e s s 4
I n p u t L e v e l s
P i c t u r e
S o u r c e S D I
Ve r t i c a l F r e q u e n c y ( f r a m e l o c k e d ) 6 0 H z
H o r i z o n ta l F r e q u e n c y 5 0 . 0 0 k H z
H o r i z o n ta l R e s o l u t i o n 1 3 6 6
Ve r t i c a l R e s o l u t i o n 7 6 8
S h a r p n e s s 4
