m40L/m46L Installation & Configuration Guide 19
Configuring an
m40L/m46L
After you select the picture source, most of the remaining setup is automatic,
although you can override the automatic settings and adjust them manually.
The source picture - from computer, video, DVD - is not always perfect in its size or
resolution; it does not always conform exactly to a standard. The display can
compensate for this.
You’ll find it easier to configure your displays when you perform the steps in the
following order:
• Select the Source (Picture) (See "Selecting the Source" on page 21)
• Adjust the Input Levels (See "Adjusting Input Levels" on page 27)
• Adjust Frequency and Phase (See "Adjusting Frequency and Phase" on page 33)
• Select the Scale Mode (See "Scale Mode Settings" on page 35)
• Adjust the Sharpness (See "Sharpness Settings" on page 41)
• Check the Image Position (See "Adjusting Position" on page 43)
• Set up Tiling for the image on multiple displays (See "Tiling a Display" on page
45)
• Adjust Scaling and Cropping (See "Zoom and Viewport" on page 49)
• Color Balance the displays (See "Adjusting Color Balance" on page 53)
