Selecting the Source
22 m40L/m46L Installation & Configuration Guide
Computer Sources
Use the HD-15 connector for standard analog inputs, the type used for years with
computers. For digital inputs, use the DVI connector. Either of these accepts pictures
of the following common standards as well as many, many others:
Component Video Sources
Component video sources are assumed to be YPbPr and the colorspace is set
accordingly.
DVD and Component Video Sources
DVD players have composite video and S-Video outputs, and sometimes have
component video outputs from three RCA connectors.
Note: HDCP (High-bandwidth Digital Content Protection) is not supported.
Composite Video and S-Video
These two inputs accept NTSC and PAL. The composite connector also accepts
SECAM video.
SD/HD SDI
This input accepts NTSC, PAL, 720p and 1080i.
Type Resolution
VGA 640 x 480
SVGA 800 x 600
XGA 1024 x 768
SXGA 1280 x 1024
WXGA 1360 x 768, 1366 x 768
UXGA 1600 x 1200
HD1920 1920 x 1080
VESA 640 x 400
