Adjusting Input Levels
32
m40L/m46L Installation & Configuration Guide
8
If the color bar pattern has a pluge, you can use it to adjust Brightness. Pluge
stands for Picture Line-Up Generation Equipment. A pluge is used to calibrate the
black level on a video monitor.
9
Although it is not required, we recommend that you save the configuration to a
memory slot. (See "Saving Configurations" on page 82.)
10
If you have more than one source coming through the same connector, adjust
input levels for each source.
Pluge
Adjust Brightness so you cannot see
the different between these two
marks,
but you can see the difference
between these two marks.
