Zoom and Viewport
50 m40L/m46L Installation & Configuration Guide
Zoom Menu Entries
Image Resolution
Shows the resolution of the source picture.
This Unit
Shows the number of pixels this display is using of all the incoming pixels.
Wall Setup
Specifies the size of the array (from the WALL & ASPECT RATIO menu) and the column
and row of this display.
Overscan
See "Overscan" on page 39.
Z o o m To p & L e ft
A r r o w s m o v e t o p a n d l e ft
0
0 0
0
I m a g e R e s o l u t i o n 1 3 6 6 x 7 6 8
T h i s U n i t 4 2 1 x 2 2 8
Wa l l S e t u p 2 x 2 2 : 1
O v e r s c a n 1 2 %
Z o o m B o t t o m & R i g h t
A r r o w s m o v e b o t t o m a n d r i g h t
0
0 0
0
I m a g e R e s o l u t i o n 1 3 6 6 x 7 6 8
T h i s U n i t 4 2 1 x 2 2 8
Wa l l S e t u p 2 x 2 2 : 1
O v e r s c a n 1 2 %
