m40L/m46L Installation & Configuration Guide

95

Specifications

Mechanical Specifications

Specification

m40L

m46L

Notes

Outside dimensions

in/lbs

mm/kg

in/lbs

mm/kg

Width

36”

923mm

43”

1094mm

Height

21”

536mm

25”

638mm

Depth

5”

126mm

5”

120mm

with front shield, add 5mm
(m40L) or 5.25mm (m46L)

Weight

63lbs

29kg

84lbs

38kg

with front shield, add 7lbs
(m40L) or 10lbs (m46L)

Shipping weight

74lbs

34kg

95lbs

43kg

Orientation

vertical and horizontal

Display color

charcoal gray

Rear clearance required

.5”

12mm

Screen dimensions

Diagonal

40”

1016mm

46”

1168mm

Width

35”

885mm

40”

1018mm

Height

20”

497mm

23”

573mm

Aspect ratio

16:9

16:9

Pixel pitch

0.648mm x 0.648mm

0.530mm x 0.530mm

Electrical and Heat Specifications

Specification

Maximum

Minimum

Typical

Notes

Video input amplitude

Separate RGB Analog

1.0V p-p

0.5V p-p

0.7V p-p

75 ohm termination

Composite Analog

5.0V p-p

0.3V p-p

75 ohm termination

TTL H and V sync

5.0V

2.5V

3.5V

TTL at 330 ohm termination

Input connectors

DVI-D x 1

Digital

15-pin HD D-sub x 1

Analog VGA
