Advanced Options
68 m40L/m46L Installation & Configuration Guide
The following actions can be selected:
• Turn Unit Off
• Turn Unit On
• Recall Slot
• Set Clock Ahead 1 Hour
• Set Clock Back 1 Hour
4 Do one of the following:
• If you selected “Recall Slot” in the previous step and want to recall a memory
slot other than the one shown, go to 5.
• If you did not select “Recall Slot” in the previous step, go to 6.
5 Use the up/down arrows to select the Slot to Recall line. Use the -/+ keys to scroll
through the list until you find the selection you want.
Note: If you select a memory slot that has not been set up, no action will occur.
6 Depending on the frequency you selected and the change you want to make,
update any of the following lines:
• Day of Week
• Year
• Month
• Date in Month
• Hour
• Minute
Note: Time is calculated using a 24-hour clock. For example, if you want your unit to turn off
at 9:30 p.m., set the Hour line to 21 and the Minute line to 30.
7 Continue setting up events until you are finished. Changes are automatically
saved each time you move from line to line.
E v e n t # ( 0 = s e t c l o c k ) 3
F r e q u e n c y We e k l y
A c t i o n R e c a l l S l o t
S l o t t o R e c a l l 4
D a y o f We e k M o n d a y
Ye a r 2 0 0 7
M o n t h 0 5
D a t e i n M o n t h 2 8
H o u r 1 2
M i n u t e 3 0
