Planar M46L User Manual
Page 106
96
m40L/m46L Installation & Configuration Guide
RCA (composite video) x 1
NTSC, PAL, SECAM
RCA (component video) x 3
Mini-DIN 4-pin (S-video) x 1
RJ45 x 2
RS232 In/Out
HD-SDI
BNC female In/Out
AC Requirements
Line voltage
115V range
230V range
130V
240V
100V
200V
115V
230V
50-60 Hz auto switching
50-60 Hz auto switching
Power
m40L
m46L
205W
278W
Current
m40L @ 115V
m40L @ 230V
m46L @ 115V
m46L @ 230V
1.78A
0.87A
2.41A
1.2A
Heat, BTUs per hour
m40L
m46L
700
950
Electrical and Heat Specifications (Continued)
Specification
Maximum
Minimum
Typical
Notes
Optical Specifications
Specification
Maximum
Minimum
Typical
Notes
Screen Brightness
m40L
m40L
m46L
m46L
700 nits/175 ftL
500 nits/150ftL
500 nits/150ftL
350 nits/100ftL
without front shield
with front shield
without front shield
with front shield
Contrast Ratio
1200:1
Full Viewing Angle
178°
C/R
>
10
Color Gamut
72%
100%
NTSC
EBU
Color CIE
±0.03 for R, G, B, W
