Selecting the Source
m40L/m46L Installation & Configuration Guide
21
Selecting the Source
Selecting the source means choosing the input connector from where the picture is
coming. Selecting the source (picture) manually is usually quicker than using the
SOURCE
button.
You’ll choose from the connectors shown in the table below, depending on whether
your display has the optional VIM installed.
Connect the power cord and turn on the power switch. If the power was already on,
and the backlights are off, press the
ON
button on the remote.
Source Connectors
Without VIM
With VIM
Analog
Analog
Digital
Digital
Component
S-Video
Composite
SD/HD SDI
Digital
input
Analog
input
Digital
loop-
through
With VIM
