Automatically Selecting the Source
m40L/m46L Installation & Configuration Guide 25
5 The next pictures show examples of the how the PICTURE menu appears when
different sources are selected. When you are finished, press MENU .
• Analog
• Digital
• S-Video
P i c t u r e
S o u r c e A n a l o g
S y n c Ty p e S e pa r a t e H & V
Ve r t i c a l F r e q u e n c y ( f r a m e l o c k e d ) 6 0 H z
H o r i z o n ta l F r e q u e n c y 5 0 . 0 0 k H z
P i x e l F r e q u e n c y 8 0 . 1 0 M H z
M o d e I D : 3 1 H P e r : 3 1 7 8 V L i n e s : 5 2 5
H o r i z o n ta l R e s o l u t i o n 1 3 6 6
Ve r t i c a l R e s o l u t i o n 7 6 8
F r e q u e n c y 1 6 0 2
P h a s e 2 2 . 5 °
S h a r p n e s s 4
I n p u t L e v e l s
P i c t u r e
S o u r c e D i g i ta l
Ve r t i c a l F r e q u e n c y ( f r a m e l o c k e d ) 6 0 H z
H o r i z o n ta l F r e q u e n c y 5 0 . 0 0 k H z
H o r i z o n ta l R e s o l u t i o n 1 3 6 6
Ve r t i c a l R e s o l u t i o n 7 6 8
S h a r p n e s s 4
I n p u t L e v e l s
P i c t u r e
S o u r c e S - Vi d e o
Vi d e o Sta n d a r d N T S C 6 0 H z / 3 . 5 8 M H z
Ve r t i c a l F r e q u e n c y ( f r a m e l o c k e d ) 6 0 H z
S h a r p n e s s
I n p u t L e v e l s
