Page 92
92
DBS 576 (USA), Revised 6/11/98
576-13-700
Chapter 4. User Maintenance
Section 700 - Operation
Table 9.
Mode Schedule Patterns - addresses & values
9. Press the HOLD key to store the entry.
Next pattern mode displays
10. To set additional mode schedules, press the volume up or
down key or press the HOLD key to move to the desired
mode.
Desired pattern mode displays
11. Repeat steps 6-10 until all patterns and modes are set.
(There are 3 total patterns with 5 start time/modes each.)
Note: Entry Positions are listed in Table 9 on page 92.
12. Press the AUTO key to exit the entry mode.
0-
Mode Schedule
displays
13. To return to the top menu level (81), press the PROG key.
OR...
To exit the User Maintenance mode, press the ON/OFF
key.
81-
User MAINT
displays
OR...
ON/OFF LED goes off
8107-0 (00-29) Hold (MMDD or HHMM or 0-5) Hold
-- VALUES --
(MMDD, HHMM, or 0-5)
-- ADDRESS NOs. (00-29) --
MODES
1st MODE
2nd MODE
3rd MODE
4th MODE
5th MODE
Pattern 1
Start Time
(HHMM)
00
02
04
06
08
Mode (0-5):
0=None
1=Day 1
2=Day 2
3=Night
4=Night (1)
5=Night (2)
01
03
05
07
09
Pattern 2
Start Time
(HHMM)
10
12
14
16
18
Mode (0-5):
0=None
1=Day 1
2=Day 2
3=Night
4=Night (1)
5=Night (2)
11
13
15
17
19
Pattern 3
Start Time
(HHMM)
20
22
24
26
28
Mode (0-5):
0=None
1=Day 1
2=Day 2
3=Night
4=Night (1)
5=Night (2)
21
23
25
27
29
Action
Result
