DBS 576 (USA), Revised 6/11/98

576-13-700

Chapter 3. System Features

Section 700 - Operation

For example, an outgoing call is an ARS Outgoing call (G) but it is also a transferred call. The SMDR
data condition code will be T to indicate that the call was an Outgoing Transfer. (A transferred call’s
condition code takes precedence over the type of call - ARS Outgoing call [G].)

Table 8.

Priority of incoming call condition codes

For example, an incoming call is a DID.DDI Incoming call (D), but it is also a transferred call. The
SMDR data condition code will be t to indicate that the call was an Incoming Transfer call. (A
transferred call’s condition code takes precedence over the type of call - DID.DDI Incoming call [D].)

Figure 1. Output data format

Condition Code: (I: Incoming call / D: DID.DDI incoming call / h: Hold incoming call / N:
Network incoming call / S:DISA incoming call / t: Transfer incoming call /
O: Outgoing call [Non LCR] / F: Call forward outside call / G: ARS outgoing call / H: Hold
outgoing call / L: LCR outgoing call / s: DISA outgoing call / T: Transfer outgoing call / W:
Network outgoing call)

Call start time (MM=01 to 12 / DD=01 to 31 / HH=00 to 23 / MM=00 to 59 / SS=00 to 59)

Call duration time (HH=00 to 23 / MM=00 to 59 / SS=00 to 59)

CO user No. (extension line No.: 0 to 9999 / CO line No.: C1 to C576)

4th

L = LCR Outgoing Call

Lowest

O = Outgoing Call

Priority

Condition

Code

Description

Highest

h or t

h = Incoming Hold
t = Incoming Transfer

2nd

D, N, or S

D = DID.DDI Incoming Call
N = Network Incoming Call
S = DISA Incoming Call

Lowest

I = Incoming Call

Priority

Condition

Code

Description
