Installation and operation precautions 1
C250P 1-25
No. Part Name Description
10 Automatic duplex unit release
lever Used to open the automatic duplex unit door when
clearing paper misfeeds
11 Automatic duplex unit door Opened when clearing paper misfeeds within the
automatic duplex unit
12 Upper right-side door release
lever Used to open the upper right-side door
13 Center right-side door Opened when clearing paper misfeeds from the
Tray 2
14 Center right-side door release
lever Used to open the center right-side door
15 Lower right-side door Opened when clearing paper misfeeds from the
Tray 3 or 4 or from the LCT
16 Lower right-side door release
lever Used to open the lower right-side door when
clearing paper misfeeds
17 Tray 4/storage tray Used for storage when the single paper feed
cabinet (tray 3) is installed
Can be loaded with up to 500 sheets of plain paper
when the double paper feed cabinet (tray 3 + tray 4)
is installed (See p. 5-15.)
18 Tray 3 Can be loaded with up to 500 sheets of plain paper
(See p. 5-15.)
19 Control panel Used to specify the various settings (See p. 1-38.)
