3 General Information
18
Symbol Name
F1 Fuse
L1 Filter Coil
LA1 Projection Lamp
M1 Scan Motor
M2 Scan Table Motor
M3 Power Unit Cooling Fan Motor
M4 Projection Lamp Cooling Fan Motor
PC1 Image Leading-Edge Position Sensor
PC2 Scan Mirror Position Sensor
PC3 Reader Position Sensor
PC4 Scan Position Sensor
PU1 Main Power Unit
PU2 Projection Lamp Regulator
PWB-A CCD Board
PWB-BB Main Control Board
PWB-C Control Panel Board
PWB-EE Printer I/F Board
PWB-G Scan Table Connecting Board
PWB-J Grayscale Memory Board
PWB-SS PC I/F Board
PWB-T Motor Drive Board
S1 Power Switch
S201 Interlock Switch
TS1 Thermostat
*PWB-J, PWB-SS : Option
