Function Mode and Adjustment 6
95
6.7.5 o5: Adjustment of the image area Lengthwise Position
1. Load the Film in the machine and make a print (scan).
Size: Letter (A4) Lengthwise
Centering:OFF
Auto Masking:ON
2. Check the black band width of top
and bottom on the print (scan)
image.
3. Refer to the charts given below.
Then, adjust for top black band
width to become the same as
bottom black band width by Function
Mode o5.
o5
Setting Border Shift Value (mm)
d5 -3 bottom frame increases
top frame increases
d6 -2
d7 -1
d8 0
d9 1
dA 2
db 3
A A
A
Top
Bottom
Feed Direction
