11.3. Live Mode
11.3. Live Mode
€ Live Screen Buttons
Button Description
Splits the screen for multi‐channel monitoring; the SVR‐470 supports 1 and
4 split screens.
Displays a selected channel in the Full Screen.
Pauses a live video. (Used to capture a still image.)
Clicking this button again replays the video.
Captures still images of a screen.
Camera Pan & Tilt control button.
Controls the Pan and Tilt operations of a connected PTZ dome camera.
This button is available only for users with the PTZ permissions that are set
to "0" at the System Setup > Password > User Authentication menu.
Camera Zoom and Focus control button.
Controls the Zoom and Focus operations of a connected camera.
This button is available only for users with the PTZ permissions that are set
to "0" at the System Setup > Password > User Authentication menu.
Turns on the audio of a connected product. (The product must be
connected or equipped with an audio device such as mic.)
Displays “Device Time”.
65
