SHR-4081N/P USER’S MANUAL

10-25

@ Backup Button

- If not playback(Stop), the video save button performs the backup function.

- If the save button is pressed, the window for backup pops up.
- Set a Start/End tome for backup and select a file format to save.
- The backup starts when the “Start” button is clicked. The backup file is saved

according to the setting route; Setup

➞ Viewer Setup ➞ Video Recording ➞

Video Location.

- To stop the backup, click the “Stop” button.

●

Calendar Window

- If the video data in on-line SHR-4081N/P was recorded, the date turns red.
- If you click the date in red, the saved video information is displayed.
- The currently selected date will be marked with a thick red box.
-

➛☎: Moves to the previous month.

❿☎: Moves to the next month.

●

Audio Volume Control, Video Brightness/Contrast Control Buttons

- Same as the control function of Monitoring Mode
- Windows 98 or ME does not support this Brightness/Contrast function.

●

Screen Split Selection Button
- Full Screen / Single / Quad / Nine-split / Sixteen split mode

Note

9 partition and 16 partition modes cannot be used in the Remote Mode. And 4 parti-
tion, 9 partition, and 16 partition modes cannot be used in the Local Mode.

Note

Video saving in the remote mode is available only when the Play/Reverse
Play/Fast Forward/Fast Backward button remains pressed down.
The backup function in the remote mode is available at the Stop status.

# File Converting Button

- This function converts .dvr files into “ .jpg” files.

- Click the “Open” button to select a *.dvr file to be converted.

- Select the JPEG Frame or AVI Video.
- If the JPEG Frame is selected, the file is converted into the “*.jpg” file by

clicking the “Start” button. The converted “*.jpg” file is saved according to the

setting route Setup

➞ Viewer Setup ➞ File Converting ➞ Jpeg Location.

- I f the AVI Video is selected, the file is converted into the “*.avi” file by clicking

the “Start” button. The converted “*.avi” file is saved according to the setting

route Setup

➞ Viewer Setup ➞ File Converting ➞ AVI Location

- Press the “Start” button to convert it to a *.Jpg file. Press Setup ➞ Viewer

Setup

➞ File Converting to save the converted *.jpg file.

- Click the Stop button to pause the file conversion.

●

Video Save(Backup) / Video Conversion / Print / Setup

! Video save button

:During the playback(Play/Reverse Play/Fast Forward/Fast Backward),
- If you select a channel in the playback and click the SAVE button, the video is

saved in a file format with the extension of .dvr in a designated folder of your PC.

- The directory in which an image will be saved, the file name, and

the video length to be saved can be set at the Setup Mode

➝ Viewer Setup.

- The video length to be saved can be set from one minute to 10 minutes.
- Click the button again to stop recording. However, manual suspension is

prohibited for 10 seconds after recording started.
