English English 12-8
SHR-4081N/P USER’S MANUAL
12-7
Classification Detailed Items Factory Setup
Event Monitoring Duration Off
Date On
OSG Display
Time On
Title On
Status On
Monitoring Setup Spot Out Channel CH1
Spot Out Event Monitor Off
Monitor Out Composite Out
PB Channel Position Right Down
Multi Channel Seq. 5 Sec
Mode On
Record Mode Video Size CIF
Setup Quality Very High
Rate 15ips(NTSC)/12.5ips(PAL)
Record Schedule Continuous Recording Off
Setup Event Recording On
Video Size CIF
Quality Very High
Event Record Mode Rate 15ips(NTSC)/12.5ips(PAL)
PreEvent 10 sec
PostEvent 1 min
Sensor State Off
Alarm Camera Camera No.
Event Record Alarm-Out None
Setup
A.O Dwell Time 10 sec
M.D State Off
Area All Area
Motion Detection Sensitivity Medium
Alarm-Out None
A.O Dwell Time 10 sec
Video Loss State Off
Video Loss Alarm-Out None
A.O Dwell Time 10 sec
5
SHR-4081N/P Smart Viewer Play
Frame Specification
FRAME Viewer Screen
VIDEO SIZE
RATE Split Mode
Half D1(N) CIF (C)
Nine-split 1 frame/sec 15 frame/sec
Quad 15 frame/sec 15 frame/sec
Single 15 frame/sec 15 frame/sec
Half D1(N) CIF (C)
Nine-split 10 frame/sec 10 frame/sec
Quad 10 frame/sec 10 frame/sec
Single 10 frame/sec 10 frame/sec
Half D1(N) CIF (C)
Nine-split 7.5 frame/sec 7.5 frame/sec
Quad 7.5 frame/sec 7.5 frame/sec
Single 7.5 frame/sec 7.5 frame/sec
Half D1(N) CIF (C)
Nine-split 5 frame/sec 5 frame/sec
Quad 5 frame/sec 5 frame/sec
Single 5 frame/sec 5 frame/sec
Half D1(N) CIF (C)
Nine-split 3 frame/sec 3 frame/sec
Quad 3 frame/sec 3 frame/sec
Single 3 frame/sec 3 frame/sec
Half D1(N) CIF (C)
Nine-split 1 frame/sec 1 frame/sec
Quad 1 frame/sec 1 frame/sec
Single 1 frame/sec 1 frame/sec
Note Note
The play frame specification of Smart Viewer varies on the setup of SHR-4081N/P
Recording Rate and Video Size or the screen split mode of Smart Viewer. The above
specification is applicable only when the main body of SHR-4081N/P is connected
with a fast network like LAN. When the main body of SHR-4081N/P is connected
with a slow network like ADSL, the play speed will be 0.5 Frame/sec. In addition,
the above specification has been defined to the recommended specification of your
PC. If your PC specification is lower than the recommended, the number of frame to
played may diminish.
15
10
7.5
5
3
1
NTSC
