English English 5-14
● Title
You can name the camera of a selected channel.
If you press the [Enter] button, the Virtual keyboard will come out.
❿☎Virtual Keyboard
If you move the cursor, you can type text by text.
Up to 15 texts can be typed.
Keyboard cannot be composed of all spaces.
Pressing Caps Lock changes the keyboard that can be selected. (2 Modes)
SHR-4081N/P USER’S MANUAL
5-13
PTZ Device
● ID
PTZ device ID from 0 to 255
● Protocol
A protocol supported by PTZ device
The following protocols are now being supported.
Samsung / Vic. / Pan. / AD / Phi. / Ern. / Pel-D / Pel-P / Vcl. / Dia. / Kal.
● Baudrate
Baudrate supported by PTZ device , 600 / 1200 / 2400 / 4800 / 9600 / 19200 /
38400
● Parity
Defines one among None, Even, and Odd.
● Data
Defines either 7 or 8.
● Stop
Defines either 1 or 2.
● Serial Mode
Defines either Half Duplex or Full Duplex.
Caution Caution
The above items shall be aligned with the PTZ device setup condition.
For the details, please refer to User’s Manual of the PTZ device manufacturer.
● Auto Seq.
You may define the duration of each channel at the Screen change channel in Live
Mode. A channel, set of Off, does not operate in Screen change Mode.
