English English 5-10
SHR-4081N/P USER’S MANUAL
5-9
HDD Mode Setup
● Disk End Mode
Stop : Stops recording when HDD is full during recording.
Overwrite : Deletes the original data and save a new data when HDD is full
during recording.
● Disk End Beep
On : Beeps when HDD is full during recording.
Off : When HDD is full, the beep sound is not heard.
Remote control Device
● MENU for Samsung Integrated Remote Control(SSC-2000)
● Device
A Remote Control Device, being connected to the RS485 port.
● ID
Unique ID of SHR-4081N/P
This unique ID is essential as SSC-2000 can control multi SHR-4081N/P DVRs.
● Baudrate
Baudrate to communicate with SSC-2000
Be sure to be identical to SSC-2000 Baudrate for communication.
● Parity
Sets up one of None / Even / Odd.
● Date
Sets up either 7 or 8.
● Stop
Sets up either 1 or 2.
● Duplex
Sets up either Half Duplex or Full Duplex.
Caution Caution
[ IEEE-1394 Hot-Plug Connect/Disconnect Function ]
Both IEEE1394 and USB support Hot-Plug.
[Backup HDD]
You may set both the USB and IEEE1394 device as the Backup HDD.
Caution Caution
[Disk End Mode Overwrite]
In the Overwrite mode, delete the old Event data in advance.
Note Note
If you select Remote Control Device, you may not PTZ device with SHR-4081N/P.
The PTZ button in front of SHR-4081N/P becomes inactivated.
Press the PTZ button and the PTZ ban icon( ) will appear.
It’s because the RS-485 port setup was done for Romote Control Device.
