SHR-4081N/P USER’S MANUAL

12-3

HDD Specifications

12-4

Item

Specification

Remark

Calendar
Event
- Normal, Panic, Schedule, Alarm, Motion,

Search Mode

Video Loss

Date/Time
Go to First
Go to Last
Backup Data

Resolution Decoding Performance

Resolution &

1Ch 4Ch

Play Back

Performance

CIF

30ips(NTSC)/25(PAL)

30 ips/1Ch

Half D1

15ips(NTSC)/12.5(PAL) 15 ips/1Ch

Full D1

7.5ips(NTSC)/6.25(PAL) 7.5 ips/1Ch

Single

➝ 1Channel Decoding

Quad

➝ 4Channel Decoding

PIP

➝ 1Channel Decoding + 1Channel Live

Display Mode

- Change the live channel.

Multi Screen

➝ 8 Channel live + 1Channel Decording

Play, Pause, Stop, 2x Digital Zoom
Fast Forward/Fast Reverse

Play Mode

- 2x, 4x, 8x, 16x, 32x, 64x
Still
Jog

➝ Still

Shuttle

➝ Fast Forward/Fast Reverse

IEEE1394 External HDD
SCSI External HDD

Backup

USB CD/DVD Writer
USB Flash Memory
Input : 8 Input

Alarm

- 5mA
Output : 4 Relay Output
- 2A/30VDC, 0.5A/125VAC
Reset : 1 Input
- 5mA

Network

Ethernet : 10/100 Base T, ADSL(PPPoE), DHCP

Serial I/F

RS-485

➝ PTZ Device Control, Remote Control Device

CPU : Pentium III, 1GHz or higher
RAM : SDRAM 256MB or higher

Remote

Graphic Accelerator : Graphic Memory

Viewer

32MB or higher DirectX : 8.1 or higher

Support OS

Win2000, WinXP
Live Image Monitoring Mode

Function

Local File Search & Play Back Mode
Remote File Search & Play Back Mode

PC Spec.

Same as Remote Viewer

Support OS

Win2000, WinXP

Backup device(External HDD, USB Memory, CD/DVD)
search and replay mode

SHR-4081N

: AC 120V (60Hz)

Input Voltage

SHR-4081N(SHR-4081N/JPN) : AC 100~230V (50/60Hz)
SHR-4081P

: AC 100~230V (50/60Hz)

SHR-4081N

: 4A

Input Current

SHR-4081N(SHR-4081N/JPN) : 4 ~ 2A
SHR-4081P

: 4 ~ 2A

Max Power Consumption

MAX 200W

Operation Temp.

0ºC ~ 40ºC

Preservation Temp.

-20ºC ~ 60ºC

Operation Humidity

20% ~ 85% RH

Preservation Humidity

20% ~ 85% RH

Size

430(W) X 88(H) X 400(D)

Weight

About 7.1Kg

Backup
Viewer

Function

PC Spec.

●

ATA HDD

Maker

Capacity

RPM

Interface

Buffer

Series Name

Model Name

Remark

160GB

200GB

250GB

160GB

200GB

250GB

300GB

160GB

200GB

250GB

300GB

400GB

160GB

200GB

250GB

Samsung

Western

Digital

Seagate

Maxtor

5400

7200

IDE, P-ATA

2MB

8MB

16MB

Spinpoint

WD Caviar SE

Barracuda 7200.7

Barracuda 7200.9

Barracuda 7200.7

Barracuda 7200.8

DiamondMax 10

DiamondMax 9

DiamondMax 10

SV1604E

SP2014N

SP2514N

WD 1600JB

WD 2000JB

WD 2500JB

WD 3000JB

ST3160023A

ST3160812A

ST3200822A

ST3250823A

ST3300831A

ST3400832A

6L160PO

6L200PO

6Y200PO

6L200RO

6B200PO

6L250RO

[CAUTION]
Check the HDD
firmware version.
(Code) : xxxx1Gxx

●

USB Memory

Maker

Model

Remark

FDISK V2

MICRO X

AnyDrive

Extreme USB Flash disk

cruzer mini

Attache

Jump Drive

Xtick Slide

Ultra Mini USM

JF110

DTI

P & C

Stormblue

ALTech

Bayon

SanDisk

PNY

GeekSquad

Lexar

Sony

Transcend

Kingston

●

External CD-RW & DVD-RW

Maker

Model Name

Interface

Remark

Sony

Plextor

Sarotech

DVD+RW DRX-810UL

DVD-Multi GSA-2164D

PX-716UF DVD+RW

Premium-U

FCD-524

USB2.0/IEEE1394

USB2.0

USB2.0/IEEE1394

USB2.0

USB2.0/IEEE1394

●

External HDD Case

Maker

Model Name

Interface

Remark

Sarotech

DVico

Makeytec

FHD 353

FX-2

MHD-998

USB2.0/IEEE1394
USB2.0/IEEE1394
USB2.0/IEEE1394

http://www.sarotech.com/

http://www.dvico.co.kr/

http://www.makeytec.com/

* DVD -R,-RW,+RW do not support.

* The USB Memory that is recognized as CD-Rom and Mass Storage(device type) on the PC is not supported.
