English English 10-24
SHR-4081N/P USER’S MANUAL
10-23
● DVR(SHR-4081N/P) Selection/Change by contacting SITE
- Same as “DVR(SHR-4081N/P)/SITE Connection” of the monitoring mode.
● Remote Mode
- This mode transfers the video data recorded in SHR-4081N/P by network for the
playback.
- Up to 4 channels are allowed for simultaneous search and playback.
- The video information at the time indicated by the timebar will be displayed in the
playback screen.
8
Search Mode
● The initial screen of search mode
- The search mode is divided into the remote mode to search and play the
SHR-4081N/P video and the local mode to play .dvr file saved in the directory
designated by your PC.
! To change to the search mode for the remote control of video recorded in
SHR-4081N/P.
@ To show the playback video.
# To change to the remote mode for the transmission of video recorded in
SHR-4081N/P through network.
$ To change to the local mode for the playback of .dvr files recorded in your PC.
% Calendar window to select “Year/Month/Day” for search.
^ To control the audio volume and video brightness/contrast.
& To change the screen split.
* Button for the Record / Convert File / Print / Setup functions.
( To control the playback of searched video.
) To display the next channel in order.
1 To change the channel and DVR or renew the calendar window
and Time Line.
2 Timeline to display the time information of search date recorded in
SHR-4081N/P.
Note Note
- When connecting to the site, select a DVR to search in the camera connection list.
- When connecting as a user, you are denied to access the search mode.
When clicking, it changes to the remote mode.
1
3 4
5
6
7
8
9
12
11
10
2
● DVR(SHR-4081N/P) Selection/Change by contacting SITE
- Select SHR-4081N/P from the Contact list.
- SHR-4081N/P turns black if contacted with the ADMIN authority and turns gray if
contacted with the USER authority.
- Without the ADMIN authority, search is not accessible.
*
*
