SHR-4081N/P USER’S MANUAL
10-11
● Time Information
- As soon as you are Connected to SHR-4081N/P, the date, weekday, and time of the
set to which the selected channel is connected.
- If SHR-4081N/P is not connected, the present date, weekday, and time of the user's
PC are displayed.
● Connection Information
- As soon as you are connected to SHR-4081N/P, the connection button will
display connection status.
- If you click the connection button here, connection will be cancelled.
● Play Screen OSD Information
! Channel no., camera name, and video size will be displayed.
Video Size (C) CIF / (N) Normal / (L) Large
@ The Video data of the current channel are recorded in your PC with REC mark
displayed.
# Audio ON/OFF Button is marked.
$ Displays the name, IP address, and play time of the current SHR-4081N/P.
% The current channel alarm status is displayed.
^ Possibility of the current channel PTZ controllability is displayed.
Note Note
# Clicking the speaker icon turns Audio of a channel on or off.
: Audio OFF : Audio ON
If you turn Audio of a SHR-4081N/P channel off, Disable will be displayed.
: Audio Disabled
✴ For the channel with Audio turned on now, use the following Audio relate button
to control Audio volume and set up MUTE.
✴ Once TCP/IP is selected, Audio will be turned off.
Note Note
% Where Alarm or Motion Detection occurs at a channel of SHR-4081N/P with
Alarm or Motion Detection established, an icon pops up on the screen real-time.
: Motion Detection : Alarm Event
Note Note
^ If you connect and set up PTZ device in SHR-4081N/P, PTZ controllability of the
channel will be displayed.
✴ Select a channel capable of PTZ and use the PTZ related buttons at the bottom to
control PTZ. (Refer to the description of PTZ Related Button.)
1 2 3
4 5 6
