ECB-862/862L
ECB-862/862L User’s Manual 63
4.5.7.3 Resources Controlled By
Default setting is “Auto (ESCD)”. This setting allows the BIOS to self detect setting and
Plug-and-Play devices during start up. The user can select and configure IRQs under
"Manual" mode.
The choice: Auto (ESCD), Manual.
4.5.7.4 IRQ Resources
These options specify the bus that the named interrupt request lines (IRQs) are used on.
These options allow you to specify IRQs for use by legacy ISA adapter cards. These
options determine if AMIBIOS should remove an IRQ from the pool of available IRQs
passed to BIOS configurable devices. The available IRQ pool is determined by reading the
ESCD NVRAM. If more IRQs must be removed from the pool, the end user can use these
PCI/PnP Setup options to remove the IRQ by assigning the option to the ISA/EISA setting.
Onboard I/O is configurable by AMIBIOS. The IRQs used by onboard I/O are configured
as PCI/PnP. The settings are PCI/PnP or ISA/EISA. The default settings are PCI/PnP.
4.5.7.5 DMA Resources
Select the devices according to your DMA requirements
4.5.7.6 PCI/VGA Palette Snoop
Enable this option to correct screen color shifts, when there is a combination of VGA cards,
accelerator cards, or MPEG cards present.
The choice: Disable, Enable.
