3.9.27 LCD Panel Connector Description (CN21)
PIN
24-bit
TFT
18-bit
TFT
P23
B0
P22
B1
P21
G0
P20
G1
P19
R0
P18
R1
P17
B2
B0
P16
B3
B1
P15
G2
G0
P14
G3
G1
P13
R2
R0
P12
R3
R1
P11
B4
B2
P10
B5
B3
P9
B6
B4
P8
B7
B5
P7
G4
G2
P6
G5
G3
P5
G6
G4
P4
G7
G5
P3
R4
R2
P2
R5
R3
P1
R6
R4
P0
R7
R5
3.9.28 CPU Fan Connector (CN22)
SIGNAL
PIN
GND 1
+12V 2
TAC 3
