ECB-862/862L
ECB-862/862L User’s Manual 7
2.3.2 Advanced High-Performance DRAM Controller
„ DRAM interface synchronous or pseudosynchronous with CPU FSB speed of 133 /
100 / 66 MHz
„ DRAM interface may be faster than CPU by 33 MHz to allow use of PC133 with 100
MHz VIA C3, Pentium III or Pentium III-M (Tualatin) CPUs or use of PC100 with 66
MHz Celeron CPU
„ DRAM interface may be slower than CPU by 33 MHz to allow use of older memory
modules with a newer CPU
„ Concurrent CPU, AGP, and PCI access
„ Different DRAM timing for each bank
„ Dynamic Clock Enable (CKE) control for SDRAM power reduction in high speed
systems
„ Mixed 1M / 2M / 4M / 8M / 16M / 32MxN DRAMs
„ 6 banks DRAMs supported (3 modules) up to 1.5 GB (256Mb DRAM technology)
„ Flexible row and column addresses
„ 64-bit data width only
„ 3.3V DRAM interface with 5V-tolerant inputs
„ Programmable I/O drive capability for MA, command, and MD signals
„ Two-bank interleaving for 16Mbit SDRAM support
„ Two-bank and four bank interleaving for 64Mbit SDRAM support
„ Supports maximum 8-bank interleave (i.e., 8 pages open simultaneously); banks are
allocated based on LRU
„ Independent SDRAM control for each bank
„ Seamless DRAM command scheduling for maximum DRAM bus utilization
„ Four cache lines (16 quadwords) of CPU to DRAM write
„ Four cache lines of CPU to DRAM read prefetch buffers
„ Read around write capability for non-stalled CPU read
„ Speculative DRAM read before snoop result
„ Burst read and write operation
„ x-1-1-1-1-1-1-1 back-to-back accesses for SDRAM from CPU or from DRAM
controller
