ECB-862/862L
ECB-862/862L User’s Manual 19
Connectors
Label Function Note
AUDIO1 Audio / TV output connector 8 x 2 box header, pitch 2.54mm
CD1 CD-ROM audio input connector 4 x 1 wafer, pitch 2.0mm
CN1 Primary IDE connector 20 x 2 box header, pitch 2.54mm
CN2 Floppy connector 17 x 2 box header, pitch 2.54mm
CN3 Power on connector 2 x 1 header, pitch 2.54mm
CN4 Reset connector 2 x 1 header, pitch 2.54mm
CN5 Secondary IDE connector 20 x 2 box header, pitch 2.54mm
CN6 Parallel port connector 13 x 2 box header, pitch 2.54mm
CN7 Serial port 2 connector 5 x 2 box header, pitch 2.54mm
CN8 HD LED 2 x 1 header, pitch 2.54mm
CN9 Reserve for internal test only 2 x 1 header, pitch 2.54mm
CN11 Power led & key lock connector 5 x 1 header, pitch 2.54mm
CN12 System fan connector 3 x 1 wafer, pitch 2.54mm
CN13 Daughter board connector A
CN14 Serial port 1 connector D-sub 9-pin male connector
CN15 Auxiliary power connector 3 x 1 wafer, pitch 2.54mm
CN16 10/100 Base-Tx Ethernet connector RJ-45
CN17 IrDA connector 5 x 2 header, pitch 2.54mm
CN18 Daughter board connector B
CN19 USB connector 5 x 2 header, pitch 2.54mm
CN20 VGA connector D-sub 15-pin female connector
CN21 LCD panel connector HIROSE DF13-40DP-1.25V
CN22 CPU fan connector 3 x 1 wafer, pitch 2.54mm
CN23 LCD inverter connector 5 x 1 wafer, pitch 2.0mm
CN24 Internal keyboard connector 5 x 1 wafer, pitch 2.54mm
CN25 PS/2 keyboard & mouse connector 6-pin mini DIN
DOC2000 M-Systems DOC 2000 socket 16 x 2 DIP socket
DIM1,2 168-pin SDRAM DIMM socket
PWR1 Power connector
VR1 LCD contrast adjustment connector 3 x 1 header, pitch 2.54mm
VR2 LCD Backlight brightness adjustment
connector 3 x 1 header, pitch 2.54mm
