ECB-862/862L
ECB-862/862L User’s Manual 23
3.9 Connector
Definitions
3.9.1 Audio / TV Output Connector (AUDIO1)
Signal
PIN
Signal
Mic 1
2
Mic Bias
AGND 3
4
AGND
Line-Out L
5
6
Line-Out R
SPK L
7
8
SPK R
Line-In L
9
10
Line-In R
AGND 11
12
Yout
GND 13
14
Cout
GND 15
16
COMP
3.9.2 CD-ROM Audio Input Connector (CD1)
Signal
PIN
CD_GND
1
CD_L 2
CD_GND
3
CD_R 4
