3.9.4 Secondary IDE Connector (CN5)
Signal
PIN
Signal
RESET# 1
2
GND
SDD7 3
4
SDD8
SDD6 5
6
SDD9
SDD5 7
8
SDD10
SDD4 9
10
SDD11
SDD3 11
12
SDD12
SDD2 13
14
SDD13
SDD1 15
16
SDD14
SDD0 17
18
SDD15
GND 19
20
NC
SDDREQ 21
22
GND
SDIOW# 23
24
GND
SDIOR# 25
26
GND
SDIORDY 27
28
IDESEL
SDDACK# 29
30
GND
IRQ15 31
32
NC
SDA1 33
34
CBLID
SDA0 35
36
SDA2
CS0 37
38
CS1
SDDACT# 39
40
GND
