ECB-862/862L
ECB-862/862L User’s Manual 57
4.5.5.13 IR Transmission Delay
If this option is enabled, transmission of data will be slower. This is recommended when
you encounter transmission problem with your device.
The choice: Disable, Enable.
4.5.5.14 UR2 Duplex Mode
Select to activate the Infrared transfer function. This default setting is “Half“.
The choice: Full, Half.
4.5.5.15 Use IR Pin
When you select to IrDA or ASKIR mode, you can define use (TX,RX ) pin.
The choice: RxD2, TxD2; IR-Rx2Tx2.
4.5.5.16 Onboard Parallel Port
Select address and interrupt for the Parallel port.
The choice: Disable, 378/IRQ7, 278/IRQ5, and 3CB/IRQ7.
4.5.5.17 Parallel Port Mode
Select an operating mode for the parallel port.
The choice: SPP, EPP, ECP, ECP+EPP, and Normal.
4.5.5.18 EPP Mode Select
Set parallel port as EPP1.7 or EPP1.9.
The choice: EPP1.7, EPP1.9.
4.5.5.19 ECP Mode Use DMA
Select a DMA channel if parallel port is set as ECP or ECP+EPP.
The choice: 1, 3.
