ECB-862/862L
ECB-862/862L User’s Manual 3
2.2 System Specifications
General Functions
• CPU: Universal Socket 370 supports Intel FC-PGA/FC-PGA2 Pentium III / Celeron
(CopperMine and Tualatin) and VIA C3 CPU with FSB up to 133MHz
• CPU Socket: Intel FC-370, Socket 370
• BIOS: Award 2Mbit Flash BIOS
• Chipset: VIA VT8602 / VT82C686B
• I/O Chipset: VT82C686B
• Memory: Onboard two 168-pin DIMM socket supports up to 1 Gbytes SDRAM
• Watchdog Timer: Can generate a system reset, IRQ15 or NMI. Software
selectable time out interval (2 sec. ~ 255 sec., 1 sec./step)
I/O Interface
• Multi I/O: EIDE x 2 (UDMA 100), FDD x 1, K/B x 1, Mouse x 1, RS-232 x 1, RS-
232/422/485 x 1, LPT x 1
• IrDA: 115kbps, IrDA 1.0 compliant
• USB: USB port x 2, USB 2.0 x 4 (5 x 2 header)
Ethernet Interface
• Chipset: Dual Realtek 8100B or Intel 82559/82559ER PCI-bus Ethernet controllers
onboard
• Ethernet Interface: PCI 100/10 Mbps, IEEE 802.3U compatible
Video Interface
• Chipset: VIA VT8602, high performance 64-bit GUI, 3D engine
• Memory: 2/ 4 /8 MB frame buffer using system memory
Resolution: Display mode:
LCD panel supports up to 1280 x 1024 @ 24 bpp
CRT displays support up to 1280 x 1024 @ 24 bpp
