User’s Manual
2 ECB-862/862L User’s Manual
2. Introduction
2.1 System Overview
The ECB-862 is an all-in-one Full-size Pentium III Single Board Computer (SBC) designed
with Intel embedded chipset VIA 8602 which supports the latest Intel Pentium III CPU with
FSB up to 133 MHz, dual PCI-bus Fast Ethernet controllers, and M-Systems DiskOnChip
socket.
Targeting on the mission critical telecommunication or industrial applications, the ECB-862
comes designed with VIA 8602 Chipset. This makes it a perfect solution for not only
popular Networking Devices like Firewall, Gateway, Router, and e-Server, but also CTI
(Computer Telephony Integration) equipments such as PBX, Digital Logger, etc.
Other onboard features include 133 MHz FSB, four UDMA 100 IDE channels, two 16C550
compatible serial ports (one RS-232, one RS-232/422/485), one multi-mode parallel port,
and two 168-pin SDRAM sockets allowing for up to 1GB of SDRAM to be installed.
