3.9.19 10/100 BASE-Tx Ethernet Connector (CN16)
Signal PIN
TxD+ 1
TxD- 2
RxD+ 3
NC 4
NC 5
RxD- 6
NC 7
NC 8
3.9.20 Signal Description – 10/100Base-Tx Ethernet Connector (CN16)
TXD+ / TXD- Ethernet 10/100Base-Tx differential transmitter outputs.
RXD+ / RXD- Ethernet 10/100Base-Tx differential receiver inputs.
3.9.21 IrDA Connector (CN17)
Signal PIN
VCC 1
NC 2
IRRX 3
GND 4
IRTX 5
3.9.22 Daughter Board Connector B (CN18)
Signal PIN Signal
NC 1 2 NC
NC 3 4
NC
NC 5 6
NC
NC 7 8
NC
NC
9 10
NC
NC
11 12
NC
TDP2
13 14
GND
RDP2
15 16
TDN2
MDAT
17 18
RDN2
MCLK 19 20 +5V
Note:
Optional daughter board is available.
