User’s Manual
22 ECB-862/862L User’s Manual
3.8.3 Clear CMOS (J3)
You can use J3 to clear the CMOS data if necessary. To reset the CMOS data, set J3 to 2-
3 closed for just a few seconds, and then remove the jumper back to 1-2 closed.
Clear CMOS (J3)
Protect* Clear CMOS
* default
3.8.4 Compact Flash Mode Select (J5)
You can use J5 to configure the Compact Flash device to be Master or Slave mode on the
secondary IDE channel.
Compact Flash Mode Select (J5)
Master* Slave
* default
3.8.5 M-Systems DiskOnChip Memory Address Select (J8)
The M-systems DiskOnChip memory address can be selected by J8. The choice is
D0000~D1FFF, D4000~D5FFF, D8000~D9FFF, or Disabled.
M-systems DiskOnChip Memory Address Select (J8)
D0000* D4000 D8000 Disabled
* default
1 2 3 1 2 3
J3
3
1
4
2
3
1
4
2
3
1
4
2
3
1
4
2
J5
1 2 1 2
