User’s Manual
32 ECB-862/862L User’s Manual
3.9.12 Serial Port 2 Connector (CN7)
Signal PIN Signal
DCD 1 2 RxD
TxD 3 4 DTR
GND 5 6 DSR
RTS 7 8 CTS
RI 9 10 NC
3.9.13 Serial Port 2 with External DB9 Connector (CN7)
Signal PIN Signal
GND 5
9 RI
DTR 4
8 CTS
TxD 3
7 RTS
RxD 2
6 DSR
DCD 1
3.9.14 HDD LED (CN8)
SIGNAL PIN
HDLED 2
+3.3V 1
3.9.15 Power Led & Key Lock Connector (CN11)
Signal PIN
GND 5
#LOCK 4
GND 3
NC 2
PWLED 1
