3.9.26 LCD Panel Connector (CN21)
Signal
PIN
Signal
ENBKL 39
40
ENVEE
M 37
38
LP
SHFCLK 35
36
FLM
GND 33
34
GND
P22 31
32
P23
P20 29
30
P21
P18 27
28
P19
P16 25
26
P17
P14 23
24
P15
P12 21
22
P13
P10 19
20
P11
P8 17
18
P9
P6 15
16
P7
P4 13
14
P5
P2 11
12
P3
P0 9
10
P1
VCON 7
8
GND
+3.3V 5
6
+3.3V
GND 3
4
GND
+5V 1
2
+5V
